Angular handrail with left/right vertical support
AT 90°
New matt black finish.
In steel.
Powder coated.
Features
Body Ø 32 cold bent, with additional fixing crosspieces near the corner, complete with fixing plates and rosettes. The fixing plates electrically isolate the product. Partially assembled device to reduce overall dimensions during transport. Powder coated. TOLLERANZE GENERALI LUNGHEZZA (mm): 0÷300 ±3, 301÷600 ±4, 601÷2000 ±5.
OTHER FEATURES:
- Material: Steel
- RAL on request: 7011, 3020, 5010, 1021, 6029
Length
A 1060 X B 660 X C 780 H mm mm
Length
A 660 x B 660 x C 780 H mm mm
Installation & Maintenance
INSTALLATION:
Fissaggio a muro tramite n° 15 tasselli.
Plugs not included in the package.
Choose anchors suitable for the type of masonry.
Diametro foro per vite: 6.3 mm.
Safety information: The device must be mounted by a competent and qualified professional installer.
The manufacturer is not responsible for the installation of the product. Periodically check that the wall fixing is solid and stable. Keep the product properly clean.
Keep the batch number shown on the label attached to the product. If the device appears unstable or damaged, it must not be used until it has been inspected and approved by a professional installer.
Certifications
TUV UNI EN ISO 9001 system certification.
Dichiarazione di conformità CE al Regolamento Europeo per i Dispositivi medici 745/2017.
Norme di riferimento: UNI EN 12182.
