Manual mechanism for washbasin
MANUAL
Made of galvanized and painted steel.
Maximum inclination 250 mm.
Operated by knobs.
Specification
Bracket, Reclining., For washbasins to be installed on brackets., Manual mechanism., Steel., Glossy white colour., RAL9016, Operated by 2 screw rods located beneath the washbasin, each equipped with a knob and black plastic tip., Adjustable sink position thanks to the bracket slots. Maximum inclination 250 mm., Washbasin-bracket fixing screws included., TUV UNI EN ISO 9001 system certification.
Features
Operated by 2 screw rods located beneath the washbasin, each equipped with a knob and black plastic tip. Adjustable sink position thanks to the bracket slots. Maximum inclination 250 mm. Washbasin-bracket fixing screws included.
OTHER FEATURES:
- Material: Steel
- EAN code: 405
- SKU: 405
- RAL on request: 7011, 3020, 5010, 1021, 6029
Collection
The Classic H49 Collection features ergonomic sanitary fixtures designed according to medical device standards, ensuring accessibility and independence in the bathroom. The collection includes:
- Sinks with a tilting mechanism for comfortable and versatile use.
- Toilets with a unified flush system, easy to install on the wall or floor; the wall-mounted version ensures maximum hygiene and cleanliness.
- Bidet, with a functional and accessible design.
Installation & Maintenance
INSTALLATION:
Fissaggio a muro tramite n° 5 tasselli.
Plugs not included in the package.
Choose anchors suitable for the type of masonry.
Diametro foro per vite: 8 mm.
Safety information: The device must be mounted by a competent and qualified professional installer.
The manufacturer is not responsible for the installation of the product. Periodically check that the wall fixing is solid and stable. Keep the product properly clean.
Certifications
TUV UNI EN ISO 9001 system certification.
