New
Custom handrails and grab bars with horizontal wall mounts.
TAILOR-MADE
New matt black finish.
In steel.
Price per meter.
Electrically insulated.
With straight wall-mounted crossbars
Powder coated.
Features
Cold bent body Ø 32, complete with support crosspiece, fixing plates and rosettes. For lengths (L) over 1000 mm, it is essential to add wall-mounted crossbars. The sections between one fixing and the next must not exceed 900 mm in length. The fixing plates electrically isolate the product. Powder coated.
OTHER FEATURES:
- Material: Steel
- RAL on request: 7011, 3020, 5010, 1021, 6029
Installation & Maintenance
INSTALLATION:
Fissaggio a muro tramite n° 3 tasselli ogni rosone.
Choose anchors suitable for the type of masonry.
Diametro foro per vite: 6.3 mm.
Safety information: The device must be mounted by a competent and qualified professional installer.
The manufacturer is not responsible for the installation of the product. Periodically check that the wall fixing is solid and stable. Keep the product properly clean.
Keep the batch number shown on the label attached to the product. If the device appears unstable or damaged, it must not be used until it has been inspected and approved by a professional installer.
Certifications
TUV UNI EN ISO 9001 system certification. CE declaration of conformity to the European Regulation for Medical Devices 745/2017.
