New
Angular grab bar with right/left-side upright post
AT 90°
New matt black finish.
In steel.
Powder coated.
Downloads disponibili:
Features
Cold-bent body Ø 32, composed of two linear parts for wall fixing and a central curve with additional fixing crosspiece, complete with fixing plates and rosettes. The three pieces are joined by two gray nylon inserts. The fixing plates electrically isolate the product. Not compatible with seat code. SDA. Powder coated. Con montante a destra o a sinistra. TOLLERANZE GENERALI LUNGHEZZA (mm): 0÷300 ±3, 301÷600 ±4, 601÷2000 ±5.
OTHER FEATURES:
- Material: Steel
- RAL on request: 7011, 3020, 5010, 1021, 6029
Installation & Maintenance
INSTALLATION:
Terminare l'assemblaggio prima dell'installazione. Fissaggio a muro tramite n° 9 tasselli.
Plugs not included in the package.
Choose anchors suitable for the type of masonry.
Diametro foro per vite: 6.3 mm.
Safety information: The device must be mounted by a competent and qualified professional installer.
The manufacturer is not responsible for the installation of the product. Periodically check that the wall fixing is solid and stable. Keep the product properly clean.
Keep the batch number shown on the label attached to the product. If the device appears unstable or damaged, it must not be used until it has been inspected and approved by a professional installer.
Certifications
TUV UNI EN ISO 9001 system certification. CE declaration of conformity to the European Regulation for Medical Devices 745/2017.
