New
Linear grab bar
Wall mounted
New matt black finish.
In steel.
With central crossbar
Powder coated.
Features
Cold bent body Ø 32, complete with fixing plates and rosettes. The fixing plates electrically isolate the product. Suitable with seat code. SDA. Powder coated.
OTHER FEATURES:
- Material: Steel
- RAL on request: 7011, 3020, 5010, 1021, 6029
Length
1200 mm mm
Length
1500 mm mm
Length
1500mm mm
Length
1800 mm mm
Length
2000 mm mm
Installation & Maintenance
INSTALLATION:
Fissaggio a muro tramite n° 9 tasselli.
Plugs not included in the package.
Choose anchors suitable for the type of masonry.
Diametro foro per vite: 6.3 mm.
Safety information: The device must be mounted by a competent and qualified professional installer.
The manufacturer is not responsible for the installation of the product. Periodically check that the wall fixing is solid and stable. Keep the product properly clean.
Keep the batch number shown on the label attached to the product. If the device appears unstable or damaged, it must not be used until it has been inspected and approved by a professional installer.
Certifications
TUV UNI EN ISO 9001 system certification. CE declaration of conformity to the European Regulation for Medical Devices 745/2017.
